Rhino RV/Boat Garage Round 14’Wx36’Lx15’H

Rhino RV/Boat Garage Round 14’Wx36’Lx15’H

Our pre-drilled frames are easily assembled with minimal hand tools. (Unlike other products where drilling or field cutting is required). Main cover and doors are made from long life UV Resistant and Fire Retardant Poly with Fabric Backing. All fabric components feature heat welded seam construction. Unit features double zipper doors on both ends to allow drive though capability, and good ventilation. Each door contains a pocket for a rigid pole and grommets for securing them up during use. Each unit comes equipped with permanent anchor system and one door roll-up kit.
RV/Boat Garage Features

Heavy Duty Galvanized Finish on All Steel Frame

Components for Maximum Strength & Long Life

Easy Bolt Together Design – all Pre-drilled & Cut

Wind Brace Support on Both Sides

Two(2) Double Zipper Doors with Bottom Pockets

One (1) complete Roll-up Door Kit

Protective Plastic Tube End Caps – All Open Ends

Standard Thread Plated Hardware Kit with Retaining

Nuts & Protective SS Washers

Quick Assembly Wrench included

Heavy Duty Poly Rope for Main Cover Tie Down

Heavy Duty Grommets on Cover & DoorsTwenty-Two (22) permanent anchors included

Eight(8) Box Shipment

Average install time – 8 to 10 hours

Specifications

Nominal Size : 14’ Wide x 36’ Long x 15’ High

Arches: Ten (10) on 48” Spacing 2-3/8” Frame Members

Standard End Door Size: 12’9″ Width x 12’6″ Height

8’6″ Wide at Top

Box Dimensions: Box 1: 86″ Long x 27″ Wide x 5″ High

Box 2: 86″ Long x 27″ Wide x 5″ High

Box 3: 86″ Long x 27″ Wide x 8″ High

Box 4: 74″ Long x 21″ Wide x 5″ High

Box 5: 68″ Long x 21″ Wide x 5″ High

Box 6: 68″ Long x 21″ Wide x 5″ High

Box 7: 50″ Long x 21″ Wide x 5″ High

Box 8: 67″ Long x 24″ Wide x 9″ High

Available Colors: Outer Colors: Green and Grey

All Interiors: White Only

Shipping Weight: 1043 lbs shipped in Eight(8) boxes Shipped via Motor Freight

Main Cover: UV Protected Fabric Backed Poly Material 10 0z. Weight. 22 Mil. Thick.

Fire Retardant Standard: Main Cover & Doors meet CPAI -84 Section 5

Anchors: Twenty-Two (22) 36” Anchor with U-Bolts & Drive Rod Std.
